ASUS Dual-Band AC1750 Gigabit Router (RT-AC66U) User Manual

1. પરિચય

This manual provides detailed instructions for the setup, operation, maintenance, and troubleshooting of your ASUS RT-AC66U Dual-Band AC1750 Gigabit Router. Please read this manual thoroughly to ensure proper use and optimal performance of your device.

The ASUS RT-AC66U Gigabit wireless dual-band router features Broadcom’s 5th generation Wi-Fi (5G WiFi) technology. It operates on both 2.4GHz and 5GHz bands, delivering data rates up to 1.75Gbps, which is three times faster than 802.11n speeds. Equipped with ASUS AiRadar technology, it amplifies transmissions for optimized signals, enhancing network coverage. The router supports ASUSWRT setup, Quality of Service (QoS) standards, multiple SSIDs, and includes two USB ports for file, DLNA, and printer server capabilities. It also features three detachable R-SMA type antennas for wider coverage and supports VPN Server functionality and IPv6.

2. ઉત્પાદન ઓવરview

The ASUS RT-AC66U router is designed to provide high-speed and reliable wireless connectivity for your home or office network. Below are key features and a visual representation of the device.

મુખ્ય લક્ષણો:

• ડ્યુઅલ-બેન્ડ AC1750 વાઇફાઇ: Utilizes 5th generation 802.11ac chipset for concurrent 2.4GHz/5GHz operation, offering speeds up to 1.75Gbps.
• ASUS AiCloud Service: Enables access, streaming, sharing, and syncing of files on the go with unlimited storage expansion.
• ગીગાબીટ ઈથરનેટ પોર્ટ્સ: Provides fast and reliable wired internet performance.
• AiRadar Technology: Optimizes wireless coverage through high-powered amplification and beam-forming with detachable antennas.
• ASUSWRT Dashboard UI: Offers a user-friendly interface for 3-step easy setup, signal monitoring, and network application control.
• Download Master: Facilitates wireless data storage and access to USB storage devices connected to the router.
• Multi-functional USB Ports: Two built-in USB ports support file sharing, printer sharing, and 3G sharing.
• વીપીએન સર્વર: Integrated VPN server functionality for secure remote access.
• IPv6 સપોર્ટ: Ready for the next generation of internet protocol.

ઉત્પાદન Views:

આકૃતિ 1: ફ્રન્ટ view of the ASUS RT-AC66U router, showcasing its design and external antennas.

Figure 2: Top-front perspective of the ASUS RT-AC66U router, highlighting the ventilation and LED indicators.

આકૃતિ 3: પાછળ view of the ASUS RT-AC66U router, showing the WAN, LAN, USB ports, and power input.

3. સેટઅપ

Follow these steps to set up your ASUS RT-AC66U router and establish an internet connection.

3.1 હાર્ડવેર કનેક્શન

1. રાઉટરને સ્થાન આપો: Place the router in a central location for optimal Wi-Fi coverage. Ensure antennas are oriented vertically for best signal.
2. મોડેમ કનેક્ટ કરો: તમારા મોડેમનો પાવર બંધ કરો. જો તેમાં બેકઅપ બેટરી હોય, તો તેને કાઢી નાખો.
3. WAN પોર્ટ કનેક્ટ કરો: Connect one end of an Ethernet cable to your modem's LAN port and the other end to the blue WAN port on the ASUS RT-AC66U router.
4. પાવર કનેક્ટ કરો: પાવર એડેપ્ટરને રાઉટરના પાવર ઇનપુટમાં અને પછી પાવર આઉટલેટમાં પ્લગ કરો.
5. પાવર ચાલુ: Turn on your modem, then turn on the ASUS RT-AC66U router. Wait for the LED indicators to stabilize.

3.2 Initial Configuration (ASUSWRT)

1. રાઉટર સાથે કનેક્ટ કરો: Connect your computer to the router either wirelessly (using the default Wi-Fi name and password found on the router's label) or via an Ethernet cable to one of the yellow LAN ports.
2. સેટઅપ પૃષ્ઠ ઍક્સેસ કરો: ખોલો એ web બ્રાઉઝર અને દાખલ કરો router.asus.com or 192.168.1.1 સરનામાં બારમાં.
3. ઑન-સ્ક્રીન સૂચનાઓને અનુસરો: The ASUSWRT dashboard UI will guide you through a 3-step setup process to configure your internet connection, Wi-Fi network name (SSID), and password.
4. Confirm Internet Status: After completing the setup, check the "Network Map" section to ensure the Internet status shows "Connected".

૩. રાઉટરનું સંચાલન

Once your router is set up, you can manage its various functions through the ASUSWRT interface or the ASUS Router app.

૫.૧ વાયરલેસ નેટવર્ક મેનેજમેન્ટ

• ડ્યુઅલ-બેન્ડ ઓપરેશન: The RT-AC66U operates on both 2.4GHz and 5GHz frequencies. You can configure separate SSIDs for each band or use Smart Connect to allow devices to automatically choose the best band.
• અતિથિ નેટવર્ક: Create up to three separate guest networks for visitors, providing internet access while isolating your main network for security.
• AiRadar Beamforming: This technology automatically detects the location of Wi-Fi devices and directs stronger signals towards them, improving range and stability.

4.2 USB Applications

The two USB 2.0 ports on the router offer versatile functionalities:

• AiDisk (File Sharing): Connect a USB storage device to create a personal cloud server for file sharing and streaming.
• Printer Server: Connect a USB printer to share it across your network.
• 3G/4G Sharing: Connect a compatible 3G/4G USB dongle to use as a primary or backup internet connection.

4.3 Network Security and Control

• AiProtection: Provides network security features, including malicious site blocking, vulnerability protection, and infected device prevention and blocking.
• Adaptive QoS: Prioritizes network traffic for specific applications (e.g., gaming, streaming) to ensure smooth performance.
• માતાપિતાના નિયંત્રણો: Manage and schedule internet access for connected devices.
• વીપીએન સર્વર: Set up a Virtual Private Network (VPN) server to securely access your home network from anywhere.

5. જાળવણી

Regular maintenance ensures your router operates efficiently and securely.

5.1 ફર્મવેર અપડેટ

Keeping your router's firmware up to date is crucial for performance, security, and new features. You can update the firmware via the ASUSWRT interface.

1. Access ASUSWRT: રાઉટરમાં લોગ ઇન કરો web interface (router.asus.com).
2. Navigate to Firmware Upgrade: પર જાઓ Administration > Firmware Upgrade.
3. અપડેટ્સ માટે તપાસો: Click "Check" to see if a new firmware version is available.
4. Perform Update: If an update is available, follow the on-screen instructions to download and install it. The router will reboot automatically after the update.

૪.૨ નિયમિત રીબૂટ

Periodically rebooting your router (e.g., once a month) can help clear its memory, resolve minor network issues, and improve overall performance.

• Soft Reboot: Log in to ASUSWRT and click the "Reboot" button at the top of the page.
• Hard Reboot: Unplug the power adapter from the router, wait 10-15 seconds, then plug it back in.

6. મુશ્કેલીનિવારણ

If you encounter issues with your ASUS RT-AC66U router, refer to the following common troubleshooting steps.

૧૬.૬ ઇન્ટરનેટ કનેક્શન નથી

1. એલઇડી સૂચકાંકો તપાસો: Ensure the Power, Wi-Fi, and Internet LEDs are solid blue. If the Internet LED is off or orange, there might be an issue with your modem or ISP connection.
2. કેબલ જોડાણો ચકાસો: Ensure all Ethernet cables (WAN, LAN) are securely connected to the correct ports on the router and modem.
3. Power Cycle Devices: Power off your modem and router. Wait 30 seconds, then power on the modem first. Once the modem is fully online (all its indicator lights are stable), power on the router.
4. Check WAN Settings: Log in to ASUSWRT and navigate to WAN > Internet Connection. Verify that your WAN connection type (e.g., PPPoE, Static IP, Automatic IP) and account settings are correct as provided by your Internet Service Provider (ISP).
5. ISP Contact: If the issue persists, contact your ISP to confirm your account status and connection details.

6.2 Poor Wi-Fi Signal or Coverage

1. રાઉટર પ્લેસમેન્ટ: Move the router to a central location, away from obstructions (thick walls, metal objects) and interference sources (microwaves, cordless phones).
2. એન્ટેના ઓરિએન્ટેશન: Adjust the router's external antennas for optimal signal reception.
3. હસ્તક્ષેપ: Change the Wi-Fi channel in ASUSWRT (Wireless > General) to avoid interference from neighboring networks. Use a Wi-Fi analyzer app to find less congested channels.
4. ફર્મવેર અપડેટ: Ensure your router's firmware is up to date (refer to Section 5.1).

6.3 Restoring to Factory Default Settings

If you experience persistent issues or forget your router's login credentials, you can restore it to its factory default settings. This will erase all custom configurations.

• Via ASUSWRT: પર જાઓ Administration > Restore/Save/Upload Setting and click "Restore".
• હાર્ડવેર રીસેટ: With the router powered on, press and hold the "Reset" button (usually a small pinhole button on the back) for about 5-10 seconds until the Power LED starts blinking. Release the button and wait for the router to reboot.

7. સ્પષ્ટીકરણો

8. વોરંટી અને સપોર્ટ

For warranty information, technical support, or further assistance, please visit the official ASUS support webસાઇટ અથવા તેમની ગ્રાહક સેવાનો સંપર્ક કરો.

• ASUS સપોર્ટ Webસાઇટ: www.asus.com/support/
• ઉત્પાદન પેજ: એમેઝોન પર ASUS સ્ટોરની મુલાકાત લો
