પરિચય
Welcome to the user manual for your T'nB iClick KBWIN Bluetooth Rechargeable Aluminum Keyboard. This guide provides essential information on setting up, operating, maintaining, and troubleshooting your new keyboard. Designed for Windows users, this slim and sleek wireless aluminum keyboard offers a comfortable typing experience and seamless connectivity.
પેકેજ સામગ્રી
- T'nB iClick KBWIN Bluetooth Rechargeable Aluminum Keyboard
- યુએસબી ચાર્જિંગ કેબલ
- વપરાશકર્તા માર્ગદર્શિકા (આ દસ્તાવેજ)
ઉત્પાદન ઓવરview
The T'nB iClick KBWIN keyboard features a slim, elegant aluminum design that complements any modern workspace. It is equipped with a full set of Windows function keys and 15 multimedia shortcuts to enhance your productivity. The integrated lithium battery provides up to 120 hours of continuous use, ensuring long-lasting performance.
સેટઅપ
કીબોર્ડ ચાર્જ કરી રહ્યું છે
Before first use, fully charge your keyboard. Connect the provided USB charging cable to the keyboard's charging port and plug the other end into a USB power source (e.g., computer USB port, USB wall adapter). The charging indicator light will illuminate during charging and turn off when fully charged. A full charge provides approximately 120 hours of continuous use.
પાવરિંગ ચાલુ/બંધ
Locate the power switch on the keyboard. Slide the switch to the 'ON' position to power on the keyboard. Slide it to the 'OFF' position when not in use to conserve battery life.
ઓપરેટિંગ સૂચનાઓ
બ્લૂટૂથ કનેક્શન
To connect your T'nB iClick KBWIN keyboard via Bluetooth:
- ખાતરી કરો કે કીબોર્ડ ચાલુ છે.
- Activate Bluetooth on your device (computer, tablet, smartphone).
- દબાવો કનેક્ટ કરો button on the keyboard (refer to the keyboard layout for exact location, usually a small button or a function key combination). The Bluetooth indicator light will start blinking, indicating it is in pairing mode.
- તમારા ઉપકરણ પર, ઉપલબ્ધ બ્લૂટૂથ ઉપકરણો માટે શોધો.
- Select "T'nB iClick KBWIN" or a similar name from the list of found devices.
- Follow any on-screen prompts to complete the pairing process. Once connected, the Bluetooth indicator light on the keyboard will stop blinking and remain solid or turn off.
સિસ્ટમ સુસંગતતા
The T'nB iClick KBWIN keyboard is compatible with:
- વિન્ડોઝ ઓપરેટિંગ સિસ્ટમ્સ
- iOS ઉપકરણો
- Android ઉપકરણો
Using Function Keys and Shortcuts
The keyboard includes standard Windows function keys (F1-F12) and 15 dedicated multimedia shortcuts. These shortcuts allow quick access to functions like volume control, media playback, and more. Refer to the key labels for specific shortcut functions.
જાળવણી
સફાઈ
To clean your keyboard, gently wipe the surface with a soft, damp cloth. Avoid using harsh chemicals or abrasive cleaners, as these can damage the finish. Ensure the keyboard is powered off before cleaning.
સંગ્રહ
When not in use for extended periods, store the keyboard in a cool, dry place. It is recommended to fully charge the keyboard before storing and to recharge it every few months to maintain battery health.
મુશ્કેલીનિવારણ
- કીબોર્ડ બ્લૂટૂથ દ્વારા કનેક્ટ થઈ રહ્યું નથી:
Ensure the keyboard is charged and powered on. Make sure Bluetooth is enabled on your device and the keyboard is in pairing mode. Try restarting both the keyboard and your device. - કીઝ જવાબ આપી રહી નથી:
Check if the keyboard is powered on and connected. If the battery is low, recharge the keyboard. If the issue persists, try re-pairing the keyboard with your device. - ટૂંકી બેટરી જીવન:
Ensure the keyboard is fully charged before use. Battery life can vary based on usage patterns. If battery life significantly decreases, contact customer support.
વિશિષ્ટતાઓ
| મોડલ નંબર | KBWIN |
| કનેક્ટિવિટી | બ્લૂટૂથ (વાયરલેસ) |
| આવર્તન શ્રેણી | 2.4 GHz |
| ઓપરેટિંગ રેન્જ | 10 મીટર સુધી |
| પાવર સ્ત્રોત | Integrated Lithium Battery (3.7V - 350 mAh) |
| બેટરી જીવન | આશરે. 120 કલાક સતત ઉપયોગ |
| સુસંગતતા | Windows, iOS, Android |
| સામગ્રી | એલ્યુમિનિયમ |
| સમાવાયેલ ઘટકો | યુએસબી કેબલ |
વોરંટી અને આધાર
ઉત્પાદક વોરંટી
This T'nB product is covered by a manufacturer's warranty of 2 years from the date of purchase. Please retain your proof of purchase for warranty claims. The warranty covers defects in materials and workmanship under normal use.
ગ્રાહક આધાર
For technical assistance, troubleshooting, or warranty inquiries, please contact T'nB customer support. Refer to the T'nB official website or product packaging for the most up-to-date contact information.
