1. પરિચય
ખરીદી બદલ આભારasing the Deeyaple 3D LED Digital Alarm Desk Clock. This versatile clock combines modern design with essential functionalities, making it a perfect addition to any room. Please read this manual carefully to ensure proper use and maintenance of your new clock.
મુખ્ય લક્ષણો:
- Easy-to-read 3D LED display with adjustable brightness.
- Remote control and on-device button settings for convenience.
- Multifunctional display: 12/24 hour mode, date, temperature.
- સ્નૂઝ ફંક્શન સાથે અલાર્મ ઘડિયાળ.
- Automatic and manual brightness adjustment.
- દિવાલ માઉન્ટિંગ અને ટેબલટોપ બંનેના ઉપયોગ માટે યોગ્ય.
2. પેકેજ સામગ્રી
કૃપા કરીને નીચેની વસ્તુઓ માટે પેકેજ તપાસો:
- Deeyaple 3D LED Digital Alarm Clock (White)
- રીમોટ કંટ્રોલ
- USB Power Cable (approx. 3 meters long)
- ડીટેચેબલ સ્ટેન્ડ
- Wall Mounting Kits (3 hooks)
- વપરાશકર્તા માર્ગદર્શિકા

Image: The Deeyaple 3D LED Digital Alarm Clock, showing the main unit, remote control, and USB power cable.
3. ઉત્પાદન ઓવરview
ફ્રન્ટ ડિસ્પ્લે:
The large 3D LED digits clearly display time, date, and temperature. The brightness can be adjusted to suit your environment.

Image: The 3D LED clock displaying time, positioned on a bedside table in a dimly lit room.
Back Panel and Remote Control:
The clock features control buttons on the back for basic settings and comes with a remote control for convenient operation from a distance.

છબી: પાછળનો ભાગ view of the clock, highlighting the control buttons and keyhole slots for wall mounting.
4. સેટઅપ
4.1 પાવર કનેક્શન:
Connect the provided USB power cable to the clock's power input port and plug the other end into a standard USB power adapter (not included) or a USB port on a computer/power bank. The clock will power on automatically.
4.2 Placement Options:
- ટેબલટોપનો ઉપયોગ: Attach the detachable stand to the bottom of the clock for stable placement on any flat surface.
- વોલ માઉન્ટિંગ: Use the three keyhole slots on the back of the clock with appropriate screws (not included) to mount it securely on a wall. Ensure the wall can support the clock's weight and that the power cable can reach a power source.

Image: The product packaging illustrating both wall-mounted and tabletop display options for the clock.
5. ઓપરેટિંગ સૂચનાઓ
5.1 Setting Time and Date:
Use the remote control or the buttons on the back of the clock to set the current time and date. Refer to the remote control's labels for specific buttons like "CLOCK" or "TIME".
- Press the "CLOCK" button on the remote to enter time setting mode.
- Use the Up/Down arrows to adjust hours and minutes.
- Press "CLOCK" again to confirm and move to date setting.
- Adjust year, month, and day using the Up/Down arrows.
- Press "CLOCK" to exit setting mode.
5.2 12/24 Hour Format:
Toggle between 12-hour and 24-hour display formats using the dedicated button on the remote control (often labeled "12/24H").
5.3 Alarm and Snooze Function:
The clock includes an alarm function with a snooze option.
- એલાર્મ સેટ કરી રહ્યું છે: Press the "ALARM" button on the remote. Use Up/Down arrows to set the alarm time. Press "ALARM" again to confirm.
- Activating Snooze: When the alarm sounds, press the "SNOOZE" button on the remote or any button on the back of the clock to activate snooze. The alarm will sound again after a set interval.
- Disabling Alarm: To turn off the alarm completely, press the "ALARM" button repeatedly until the alarm icon disappears from the display.

Image: The clock displaying an alarm time and a separate image showing the snooze function activated.
5.4 Brightness Control:
The clock offers multiple brightness levels and an automatic dimming feature.
- મેન્યુઅલ એડજસ્ટમેન્ટ: Use the "BRIGHT" button on the remote to cycle through 3 brightness levels (High, Medium, Low) and an OFF state.
- સ્વચાલિત ડિમિંગ: The clock can automatically adjust its brightness based on ambient light conditions. This feature ensures optimal visibility during the day and reduces brightness for comfortable viewરાત્રે ing.

Image: Illustration of the clock displaying time at three different brightness levels, from brightest to dimmest.
5.5 Temperature and Date Display:
The clock can cycle through time, date, and temperature displays. Use the "TEMP" button on the remote to switch between these modes or activate the loop display.

Image: The clock demonstrating its loop display mode, showing transitions between time, date, and temperature readings.
6. જાળવણી
- ઘડિયાળની સપાટીને નરમ, સૂકા કપડાથી સાફ કરો. ઘર્ષક ક્લીનર્સ અથવા સોલવન્ટનો ઉપયોગ કરશો નહીં.
- Keep the clock away from direct sunlight, high temperatures, and high humidity.
- Ensure the USB cable is not kinked or damaged.
- If the clock is unplugged, it has a memory function to retain time settings, powered by the included Lithium Ion batteries.
7. મુશ્કેલીનિવારણ
| સમસ્યા | સંભવિત કારણ | ઉકેલ |
|---|---|---|
| ઘડિયાળ ચાલુ થતી નથી. | પાવર સપ્લાય નથી કે ખામીયુક્ત કેબલ નથી. | Ensure the USB cable is securely connected and the power adapter is working. Try a different USB port or adapter. |
| ડિસ્પ્લે ખૂબ તેજસ્વી/મંદ છે. | બ્રાઇટનેસ સેટિંગને સમાયોજિત કરવાની જરૂર છે. | Press the "BRIGHT" button on the remote to cycle through brightness levels. Check if automatic dimming is enabled. |
| સમય/તારીખ ખોટી છે. | Not set correctly or power interruption. | Follow instructions in Section 5.1 to reset time and date. The clock has memory function, but a prolonged power outage might require re-setting. |
| એલાર્મ વાગતો નથી. | એલાર્મ સેટ નથી અથવા અવાજ ખૂબ ઓછો છે. | Ensure the alarm is activated and set to the correct time. Check for any mute settings (though the product description mentions "mute", it's likely for button sounds, not alarm). |
| Clock flickering or acting erratically. | Power instability or internal issue. | Try unplugging and re-plugging the clock. If the issue persists, contact customer support. |
8. સ્પષ્ટીકરણો
| લક્ષણ | વિગત |
|---|---|
| બ્રાન્ડ | Deeyaple |
| મોડલ નંબર | CK-LED1302 |
| રંગ | સફેદ |
| ડિસ્પ્લે પ્રકાર | Digital (3D LED) |
| ઉત્પાદન પરિમાણો | ૨.૩૬"પગ x ૪.૦૬"પગ |
| વસ્તુનું વજન | 8.8 ઔંસ |
| પાવર સ્ત્રોત | કોર્ડેડ ઇલેક્ટ્રિક (USB) |
| ખાસ લક્ષણો | Adjustable Brightness, 3D Floating Display, Auto Dimmable, Snooze, Calendar Display, Temperature Display |
| માઉન્ટિંગ પ્રકાર | વોલ માઉન્ટ, ટેબલટોપ |
| બેટરીઓ | 2 Lithium Ion batteries (included for memory function) |
9. વોરંટી અને સપોર્ટ
Deeyaple is committed to providing quality products. For any questions, concerns, or technical support regarding your 3D LED Digital Alarm Desk Clock, please contact our customer service team through the retailer's platform where you purchased the product or visit the official Deeyaple store online.
Please retain your purchase receipt for warranty purposes. Specific warranty details may vary by region and retailer.
