BWT RC50 રોબોટિક પૂલ ક્લીનર વપરાશકર્તા માર્ગદર્શિકા

1. પરિચય

Thank you for choosing the BWT RC50 Robotic Pool Cleaner. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new pool cleaner. Please read this manual thoroughly before using the product and keep it for future reference.

2. સલામતી માહિતી

Always observe the following safety precautions to reduce the risk of injury, electric shock, or damage to the unit.

• ઉપયોગ કરતા પહેલા બધી સૂચનાઓ કાળજીપૂર્વક વાંચો.
• કોઈપણ જાળવણી અથવા સફાઈ કરતા પહેલા ખાતરી કરો કે વીજ પુરવઠો બંધ છે.
• Do not operate the cleaner if the power cord is damaged.
• Keep children and pets away from the pool area when the cleaner is in operation.
• Only use the cleaner in water temperatures between 10°C (50°F) and 35°C (95°F).
• Do not use the cleaner if there are people in the pool.
• ક્લીનરનો ઉપયોગ ન હોય ત્યારે ઠંડી, સૂકી જગ્યાએ સંગ્રહ કરો.

3. ઉત્પાદન ઓવરview

3.1. ઉત્પાદન વર્ણન

The BWT RC50 is a compact robotic pool cleaner designed to navigate tight spaces created by forgotten toys on the pool floor and other obstacles. Its hydrodynamic design reduces drag, so less power is needed to drive it through the water. BWT robotic cleaners are intuitive and easy to use, at the touch of a button the RC50 gets to work all by itself. The RC50 is fitted with the state of art 4D hyperfine filter. This filter consists of elastic 4D loops that trap even the tiniest particles. Their vibrating motion prevents clogging to maximize water throughput and suction power. The transparent filter lid makes it easy to see if the filter needs to be washed. For additional convenience, we’ve taken away the need to remove the filter cartridge from its housing. Simply lift a lever to release the filter and pull the filter cartridge out of the cleaner and wash it out. BWT robotic cleaners feature the most powerful suction of any robot on the market. They can significantly increase their suction power through precise adjustment of the height of intake valves. The closer they are to the surface being vacuumed, the more powerful the suction. Suction can be adjusted to efficiently capture the type of debris to be picked up. Thus, close to a beach for example, the intake valves can be set down low to effortlessly remove every grain of sand.

3.2. મુખ્ય લક્ષણો

• 4 PVC Scrubbing Wheels for effective cleaning.
• Dual Tread Breezer Technology for enhanced maneuverability.
• Anti Tangle Swivel 59 ft Cord to prevent tangling during operation.
• Premium Storage Caddy for easy storage.
• Selectable Cleaning Cycle Durations: 1.5 and 2 hours.
• Advanced 4D Hyperfine Filter for trapping even the tiniest particles.
• Adjustable Suction Power for efficient debris capture.

3.3. ઉત્પાદન ઘટકો

Figure 1: BWT RC50 Robotic Pool Cleaner (Front-side view). Shows the main body, handle, and scrubbing wheels.

Figure 2: BWT RC50 Robotic Pool Cleaner (Front view). Highlights the front scrubbing wheels and intake area.

Figure 3: BWT RC50 Robotic Pool Cleaner (Top-down view). Shows the handle and the overall compact design.

4. સેટઅપ

4.1. અનપેકિંગ

1. Carefully remove the BWT RC50 cleaner and all accessories from the packaging.
2. Verify that all components listed in the packing list are present and undamaged.
3. Retain the packaging for future storage or transportation.

4.2. Initial Placement and Power Connection

1. Ensure the pool is free of large debris that could obstruct the cleaner.
2. Uncoil the 59 ft anti-tangle swivel cord completely.
3. Connect the power supply unit to a grounded electrical outlet.
4. Gently lower the BWT RC50 into the pool. Ensure it sinks to the bottom and all trapped air escapes.
5. Position the power supply unit at least 3.5 meters (11.5 feet) from the edge of the pool.

5. ઓપરેટિંગ સૂચનાઓ

૫.૨. સફાઈ ચક્ર શરૂ કરવું

The BWT RC50 is designed for intuitive operation.

1. Once the cleaner is submerged and connected to power, locate the touch control panel.
2. Select your desired cleaning cycle duration: 1.5 hours or 2 hours. The cleaner will begin operation automatically.
3. The cleaner will navigate the pool floor using its self-propelled mechanism, 4 PVC scrubbing wheels, and Dual Tread Breezer Technology to ensure thorough cleaning.

5.2. સક્શન પાવર એડજસ્ટ કરવો

The BWT RC50 allows for precise adjustment of the height of its intake valves to optimize suction power based on the type of debris.

• For fine debris like sand, adjust the intake valves to be closer to the pool surface.
• For larger debris, the intake valves can be set to a higher position.
• Refer to the diagrams in the quick start guide (not included in this manual) for specific instructions on adjusting intake valve height.

5.3. Ending a Cleaning Cycle

The cleaner will automatically stop at the end of the selected cleaning cycle. To manually stop the cleaner, press the power button on the control panel.

To remove the cleaner from the pool, gently pull the anti-tangle swivel cord until the cleaner is within reach. Use the handle to lift it out of the water. Allow excess water to drain before placing it on a clean surface.

6. જાળવણી

Regular maintenance ensures the longevity and optimal performance of your BWT RC50.

6.1. Cleaning the 4D Hyperfine Filter

The transparent filter lid allows you to easily see when the filter needs cleaning.

1. Ensure the cleaner is disconnected from the power supply.
2. Lift the lever to release the filter housing.
3. Pull the filter cartridge out of the cleaner.
4. Rinse the filter cartridge thoroughly with a garden hose until all debris is removed. The 4D elastic loops are designed to prevent clogging.
5. Reinsert the clean filter cartridge into the cleaner and secure the lever.

૩. સામાન્ય સફાઈ અને સંગ્રહ

• After each use, rinse the exterior of the cleaner with fresh water to remove any pool chemicals or debris.
• Inspect the scrubbing wheels and treads for any trapped debris and remove them if necessary.
• Store the BWT RC50 in its Premium Storage Caddy in a cool, dry, and shaded area, away from direct sunlight and extreme temperatures.
• Ensure the power cord is neatly coiled and not kinked during storage.

7. મુશ્કેલીનિવારણ

This section addresses common issues you might encounter with your BWT RC50.

If you encounter an issue not listed here or if the suggested solutions do not resolve the problem, please contact BWT customer support.

8. સ્પષ્ટીકરણો

9. વોરંટી અને સપોર્ટ

9.1. વોરંટી માહિતી

The BWT RC50 Robotic Pool Cleaner comes with a મર્યાદિત વોરંટી. Please refer to the warranty card included with your product for specific terms, conditions, and duration of coverage. Keep your proof of purchase for warranty claims.

9.2. ગ્રાહક આધાર

For technical assistance, troubleshooting not covered in this manual, or warranty inquiries, please contact BWT customer support.

• Webસાઇટ: Visit the BWT Store on Amazon (સામાન્ય ઉત્પાદન માહિતી માટે)
• ઈમેલ: Refer to your product packaging or warranty card for direct contact email.
• ફોન: Refer to your product packaging or warranty card for direct contact phone number.

When contacting support, please have your model number (RC50 / RU2D-TRS0-T5C76) and proof of purchase readily available.

૧૦. સત્તાવાર ઉત્પાદન વિડિઓઝ

No official product videos from the seller were provided for this model. Please refer to the written instructions and images for guidance.
