1. પરિચય અને ઓવરview
The Umarex AER16 is an electric-powered, full-auto steel BB airgun designed for recreational shooting. This manual provides essential information for the safe and proper operation, maintenance, and troubleshooting of your AER16 air rifle.
Figure 1: Umarex AER16 Air Rifle, main view.
મુખ્ય લક્ષણો:
- Electric-powered full-auto steel BB airgun.
- Launches up to 650 rounds (10-12 magazines) on a full battery charge.
- Features a drop-free magazine with a 55-round capacity.
- Shoots .177 caliber steel BBs at up to 430 feet per second (FPS).
- Equipped with a smart LED MOSFET for precise control and performance.
- Easily switch between safe, semi-auto, and full-auto firing modes.
- Offers multiple mounting options for accessories.
- Includes adjustable and removable flip-up sights, a 650-round speedloader, charging cable, and an 11.1V 1100 mAh Li-Po battery.
- Compatible with spare magazine part number: 2252127.
ઉત્પાદન ઓવરview વિડિઓ:
વિડિઓ ૧: એક ઓવરview of the Umarex AER16 air rifle, highlighting its key features and operation.
2. સલામતી માહિતી
WARNING: This is not a toy. Misuse may cause serious injury or death. Always handle with extreme caution.
દરખાસ્ત 65 ચેતવણી: આ ઉત્પાદનમાં એવા રસાયણો છે જે કેલિફોર્નિયા રાજ્યમાં જાણીતા છે જે કેન્સર અને જન્મજાત ખામીઓ અથવા અન્ય પ્રજનન નુકસાન પહોંચાડે છે.
- Always wear eye protection when handling or operating the air rifle.
- Treat every airgun as if it were loaded.
- Never point the air rifle at anything you do not intend to shoot.
- જ્યાં સુધી તમે ગોળીબાર કરવા તૈયાર ન થાઓ ત્યાં સુધી તમારી આંગળી ટ્રિગરથી દૂર રાખો.
- તમારા લક્ષ્ય અને તેનાથી આગળ શું છે તેની ખાતરી રાખો.
- Store the air rifle unloaded and separate from ammunition.
- બાળકોની પહોંચથી દૂર રાખો.
- ઉપયોગ કરતા પહેલા બધી સૂચનાઓ વાંચો અને સમજો.
3. પેકેજ સામગ્રી
પેકેજ ખોલતી વખતે, ખાતરી કરો કે બધા ઘટકો હાજર છે અને તેમને કોઈ નુકસાન થયું નથી:
- Umarex AER16 Electric-Powered Full Auto .177 Caliber BB Gun Air Rifle
- 55-round drop-free magazine
- 650-round speedloader
- 11.1V 1100 mAh Li-Po battery
- બેટરી ચાર્જિંગ કેબલ
- Adjustable and removable flip-up sights
આકૃતિ 2: ફ્રન્ટ view of the Umarex AER16 product packaging.
4. સેટઅપ
૫.૧ બેટરી ચાર્જિંગ અને ઇન્સ્ટોલેશન
The AER16 is powered by an 11.1V 1100 mAh Li-Po battery. Ensure the battery is fully charged before first use.
- Connect the provided charging cable to the battery and a suitable USB power source.
- Allow the battery to charge completely. Refer to the charger's indicator for charging status.
- Locate the battery compartment, typically within the buttstock or handguard.
- Carefully insert the charged battery into the compartment and connect it to the air rifle's power connector.
- બેટરી કમ્પાર્ટમેન્ટને સુરક્ષિત રીતે બંધ કરો.
આકૃતિ 3: ફ્રન્ટ view of the AER16 air rifle, showing the barrel and handguard.
૪.૩ BB લોડ કરી રહ્યું છે
The AER16 uses .177 caliber steel BBs and comes with a 55-round drop-free magazine and a 650-round speedloader.
- Remove the magazine from the air rifle by pressing the magazine release button.
- Use the included speedloader to fill the magazine with .177 caliber steel BBs. Ensure BBs are loaded correctly to prevent jams.
- Insert the loaded magazine firmly into the magazine well until it clicks into place.
આકૃતિ 4: ક્લોઝ-અપ view of the AER16's receiver and magazine.
Figure 5: The 55-round drop-free magazine for the AER16.
4.3 Adjusting Buttstock
The AER16 features an adjustable buttstock for comfortable shooting positions.
- Locate the adjustment lever on the underside of the buttstock.
- Press the lever and slide the buttstock to your desired length.
- Release the lever to lock the buttstock in position.
આકૃતિ 6: પાછળ view of the AER16, showing the adjustable buttstock.
4.4 Sights and Accessories
The air rifle includes adjustable and removable flip-up sights and offers multiple mounting options for additional accessories on its rail system.
આકૃતિ 7: બાજુ view of the AER16, illustrating the rail system for accessories.
5. ઓપરેટિંગ સૂચનાઓ
5.1 Safety Selector
The AER16 features a safety selector with three positions: SAFE, SEMI, and AUTO.
- સલામત: Prevents the air rifle from firing. Always engage the safety when not actively shooting.
- અર્ધ: Allows for single shots with each pull of the trigger.
- UTટો: Enables full-automatic firing, continuously shooting as long as the trigger is held down and ammunition is available.
Figure 8: Close-up of the safety selector on the AER16.
5.2 Firing the Air Rifle
- Ensure the magazine is loaded and properly inserted.
- Point the air rifle in a safe direction towards your target.
- Move the safety selector to the desired firing mode (SEMI or AUTO).
- Place your finger on the trigger and pull to fire.
- After firing, always return the safety selector to the SAFE position.
6. જાળવણી
Regular maintenance ensures the longevity and optimal performance of your Umarex AER16 air rifle.
6.1 સફાઈ
- Wipe down the exterior of the air rifle with a clean, dry cloth after each use to remove dirt and moisture.
- Periodically clean the barrel using a .177 caliber cleaning rod and patches.
- Do not use petroleum-based lubricants on plastic or rubber components.
6.2 બેટરી કેર
- Always use the provided charging cable or a compatible Li-Po charger.
- Do not overcharge or completely discharge the battery.
- સીધા સૂર્યપ્રકાશ અને અતિશય તાપમાનથી દૂર ઠંડી, સૂકી જગ્યાએ બેટરીનો સંગ્રહ કરો.
- જો લાંબા સમય સુધી સ્ટોરેજ કરવામાં આવે, તો બેટરીને લગભગ 50% ક્ષમતા સુધી ચાર્જ કરો.
7. મુશ્કેલીનિવારણ
This section addresses common issues you might encounter with your AER16 air rifle.
| સમસ્યા | સંભવિત કારણ | ઉકેલ |
|---|---|---|
| Air rifle does not fire. | Battery is not charged or connected; Safety is engaged; Magazine is empty or not properly inserted. | Charge and connect battery; Disengage safety; Load and properly insert magazine. |
| Low FPS or inconsistent shots. | Low battery charge; Incorrect BBs used; Barrel obstruction. | Recharge battery; Use recommended .177 steel BBs; Clean barrel. |
| BBs not feeding. | Magazine improperly loaded or damaged; Incorrect BB size. | Reload magazine correctly; Inspect magazine for damage; Ensure .177 steel BBs are used. |
If the issue persists after attempting these solutions, please contact Umarex customer support.
8. સ્પષ્ટીકરણો
| લક્ષણ | વિગત |
|---|---|
| બ્રાન્ડ | Umarex |
| મોડેલનું નામ | Er16 |
| ભાગ નંબર | 2252126 |
| યુપીસી | 723364521263 |
| કેલિબર | .177 Caliber Steel BBs |
| મેક્સ એફપીએસ | 430 FPS સુધી |
| પાવર પ્રકાર | Battery, Electric (AEG) |
| બેટરી | 11.1V 1100 mAh Li-Po (Included) |
| મેગેઝિન ક્ષમતા | ૪૦૦ રાઉન્ડ |
| Total Rounds (on full charge) | Up to 650 Rounds (approx. 10-12 mags) |
| ફાયરિંગ મોડ્સ | Safe, Semi-Auto, Full-Auto |
| બેરલ સામગ્રી | ધાતુ |
| ફ્રેમ સામગ્રી | પોલિમર |
| રંગ | કાળો |
| આઇટમ પેકેજ પરિમાણો | 34.02 x 10.71 x 3.86 ઇંચ |
| પેકેજ વજન | 3.24 કિલોગ્રામ |
| સૂચિત વપરાશકર્તાઓ | યુનિસેક્સ-પુખ્ત |
| તારીખ પ્રથમ ઉપલબ્ધ | 23 જાન્યુઆરી, 2024 |
આકૃતિ 9: પાછળ view of the AER16 product packaging, showing UPC and manufacturer details.
9. વોરંટી અને સપોર્ટ
The Umarex AER16 Electric-Powered Full Auto .177 Caliber BB Gun Air Rifle is covered by a manufacturer's warranty.
For warranty claims, technical support, or additional information, please visit the official Umarex USA webસાઇટ અથવા તેમના ગ્રાહક સેવા વિભાગનો સંપર્ક કરો.
Official Umarex USA Store: Umarex USA Store on Amazon
ઉત્પાદક Webસાઇટ: umarexairguns.com
