Qlima SRE 9046 C-2 પેરાફિન/પેટ્રોલિયમ હીટર વપરાશકર્તા માર્ગદર્શિકા

1. પરિચય

This manual provides essential information for the safe and efficient operation, setup, and maintenance of your Qlima SRE 9046 C-2 electronic paraffin/petroleum heater. Please read these instructions carefully before using the appliance and retain them for future reference.

The Qlima SRE 9046 C-2 is a high-performance electronic heater designed to efficiently warm spaces up to 76 m² (or 190 m³). It features an electronically controlled burner for optimal combustion efficiency, a 9-liter fuel tank, and operates quietly. Key features include a timer function, energy-saving mode, child safety lock, odor reduction system, anti-tilt safety, and overheat protection. An integrated fan ensures uniform heat distribution.

This appliance is GS and NF approved and bears the CE label, ensuring compliance with European safety standards.

2. મહત્વપૂર્ણ સલામતી માહિતી

Always adhere to the following safety guidelines to prevent accidents, injury, or damage to property.

• વેન્ટિલેશન: Ensure adequate ventilation in the room where the heater is used. Do not use in unventilated spaces.
• બળતણ: Use only pure paraffin or petroleum lamp oil specifically designed for heaters. Never use gasoline, diesel, or other flammable liquids.
• પ્લેસમેન્ટ: Place the heater on a stable, level surface, away from flammable materials such as curtains, furniture, and bedding. Maintain a minimum distance of 1 meter (3 feet) from any combustible objects.
• દેખરેખ: Do not leave the heater unattended, especially when children or pets are present.
• ઢાંકશો નહીં: Never cover the heater, as this can lead to overheating and fire.
• ખસેડવું: Do not move the heater while it is operating or still hot.
• જાળવણી: કોઈપણ જાળવણી અથવા સફાઈ કરતા પહેલા પાવર સપ્લાયને ડિસ્કનેક્ટ કરો.
• ફક્ત આંતરિક ઉપયોગ: આ ઉપકરણ ફક્ત ઇનડોર ઉપયોગ માટે રચાયેલ છે.
• પાવર કોર્ડ: Do not place the power cord under carpets or in areas where it can be tripped over or damaged.

3. ઉત્પાદન ઓવરview

Familiarize yourself with the main components of your Qlima SRE 9046 C-2 heater.

3.1 મોરચો View

3.2 નિયંત્રણ પેનલ

• પ્રદર્શન: Shows current temperature, set temperature, time, and error codes.
• પાવર બટન (લાલ): હીટર ચાલુ અથવા બંધ કરે છે.
• સેટ બટન: Used to access and confirm settings.
• TEMP/TIME Buttons (Up/Down Arrows): Adjusts temperature settings or timer values.
• ટાઈમર બટન: Activates or deactivates the timer function.
• ECO બટન: Engages the energy-saving mode.
• ચાઇલ્ડ લૉક બટન: Activates or deactivates the child safety lock.

4. સેટઅપ

4.1 અનપેકિંગ

Carefully remove the heater from its packaging. Inspect the appliance for any signs of damage. Keep packaging materials out of reach of children.

4.2 પ્લેસમેન્ટ

Place the heater on a firm, level, and heat-resistant surface. Ensure there is sufficient clearance around the heater for proper air circulation (minimum 1 meter from walls, furniture, and other objects). Do not place the heater near heat-sensitive materials or in direct sunlight.

4.3 Fueling the Heater

The Qlima SRE 9046 C-2 uses paraffin/petroleum fuel. Always use high-quality, pure paraffin or petroleum lamp oil to ensure optimal performance and prevent damage to the heater. The fuel tank has a capacity of 9 liters.

1. Ensure the heater is turned off and cool before refueling.
2. Locate the removable fuel tank, typically found on the side or back of the unit.
3. Carefully remove the fuel tank from the heater.



4. ફ્યુઅલ કેપને સ્ક્રૂ કાો.



5. Fill the tank with the appropriate fuel, being careful not to overfill. Do not spill fuel.
6. Securely replace the fuel cap and wipe away any spilled fuel.
7. Carefully reinsert the fuel tank into the heater until it clicks into place.

4.4 પાવર કનેક્શન

પાવર કોર્ડને ગ્રાઉન્ડેડ ઇલેક્ટ્રિકલ આઉટલેટ સાથે જોડો. ખાતરી કરો કે વોલ્યુમtage matches the heater's requirements (240 Volts AC).

5. ઓપરેટિંગ સૂચનાઓ

5.1 પાવર ચાલુ/બંધ

• To turn on: Press the red પાવર બટન. The heater will initiate a startup sequence.
• To turn off: Press the red પાવર બટન again. The heater will enter a cool-down phase before shutting down completely.

5.2 તાપમાન સેટ કરવું

• દબાવો સેટ તાપમાન સેટિંગ મોડમાં પ્રવેશવા માટે બટન.
• નો ઉપયોગ કરો TEMP/TIME Up/Down Arrows to adjust the desired room temperature.
• દબાવો સેટ again to confirm, or wait a few seconds for the setting to be automatically saved.

5.3 ટાઈમર કાર્ય

The timer allows you to program the heater to turn on or off at a specific time.

• દબાવો ટાઈમર બટન.
• નો ઉપયોગ કરો TEMP/TIME Up/Down Arrows to set the desired on/off time.
• દબાવો ટાઈમર બટન again to activate the timer. The timer indicator will illuminate.

5.4 Energy-Saving Mode (ECO)

The ECO mode helps reduce fuel consumption by automatically adjusting the heating output to maintain a comfortable temperature more efficiently.

• દબાવો ECO બટન to activate or deactivate the energy-saving mode. The ECO indicator will light up when active.

5.5 બાળ સુરક્ષા લોક

To prevent accidental operation or changes to settings by children, activate the child safety lock.

• દબાવો અને પકડી રાખો ચાઇલ્ડ લૉક બટન for a few seconds until the lock indicator appears on the display.
• નિષ્ક્રિય કરવા માટે, દબાવો અને પકડી રાખો ચાઇલ્ડ લૉક બટન again until the indicator disappears.

6. જાળવણી

નિયમિત જાળવણી તમારા હીટરની ટકાઉપણું અને કાર્યક્ષમ કામગીરી સુનિશ્ચિત કરે છે.

6.1 નિયમિત સફાઈ

• હીટરને હંમેશા અનપ્લગ કરો અને સફાઈ કરતા પહેલા તેને સંપૂર્ણપણે ઠંડુ થવા દો.
• સોફ્ટ સાથે બાહ્ય સપાટીઓ સાફ કરો, ડીamp કાપડ ઘર્ષક ક્લીનર્સ અથવા સોલવન્ટનો ઉપયોગ કરશો નહીં.
• Clean the air intake and outlet grilles regularly to prevent dust buildup, which can impede airflow.

6.2 ફ્યુઅલ ફિલ્ટર

Check the fuel filter periodically for any debris or blockages. Refer to the full product manual for instructions on how to access and clean or replace the fuel filter.

6.3 સંગ્રહ

If storing the heater for an extended period:

• Empty the fuel tank completely.
• Clean the heater thoroughly.
• Store the heater in a dry, dust-free location, away from direct sunlight and extreme temperatures.

7. મુશ્કેલીનિવારણ

If you encounter issues with your Qlima SRE 9046 C-2 heater, consult the following common troubleshooting tips:

• હીટર ચાલુ નથી થતું: Check if the power cord is securely plugged in and if there is power to the outlet. Ensure the fuel tank is not empty and is correctly inserted.
• અસામાન્ય ગંધ: A slight odor may occur during initial use. If a strong or persistent odor is present, ensure proper ventilation and check for fuel spills. Using incorrect or contaminated fuel can also cause odors.
• ભૂલ કોડ્સ: If an error code appears on the display, consult the comprehensive product manual for specific code meanings and recommended actions. Common issues might relate to fuel levels, ventilation, or internal sensor readings.
• ઘટાડેલી હીટિંગ કામગીરી: Check if the air intake and outlet grilles are clean and unobstructed. Ensure the room size is within the heater's capacity.
• સ્વચાલિત શટડાઉન: The heater is equipped with safety features like anti-tilt and overheat protection. If it shuts down unexpectedly, check if it has been knocked over or if the air vents are blocked. Allow it to cool down before restarting.

If the problem persists after attempting these solutions, contact Qlima customer support or a qualified service technician.

8. સ્પષ્ટીકરણો

9. વોરંટી અને સપોર્ટ

The Qlima SRE 9046 C-2 heater comes with a 4 વર્ષની ઉત્પાદન વોરંટી. આ વોરંટી સામાન્ય ઉપયોગ હેઠળ સામગ્રી અને કારીગરીમાં ખામીઓને આવરી લે છે.

For warranty claims, technical support, or spare parts inquiries, please contact your authorized Qlima dealer or visit the official Qlima website for customer service contact information. Please have your model number (SRE 9046 C-2) and proof of purchase available when contacting support.
